| · | Function: Cooling/Heating | · | Type: Single Split, Inverter |
| · | Capacity - Cooling: 2.5 kW | · | Capacity - Heating: 3.0 kW |
| · | Capacity - Cooling (min. - max.): 0.9 - 3.2 kW | · | Capacity - Heating (min. - max.): 0.9 - 4.5 kW |
| · | Power input - Cooling: 0.69 kW | · | Power input - Heating: 0.83 kW |
| · | Power input - Cooling (min. - max.): 0.25 - 1.00 kW | · | Power input - Heating (min. - max.): 0.17 - 1.36 kW |
| · | EER / Star rating - Cooling: 3.62 / 6.0 | · | COP / Star rating - Heating: 3.61 / 5.0 |
| · | Sensible - Cooling: 2.06 kW | · | Dry Mode (Moisture Removal, Litre/hr): 0.5 |
|
|
|
| · | H2 Capacity - Heating*: 2.69 kW | · | H2 Power input - Heating*: 0.79 kW |
| · | H2 COP - Heating*: 3.42 | | |
|
|
|
| · | Operation Range - Cooling: -10 / +46°C | · | Operation Range - Heating: -15 / +24°C |
| · | Sound Level - Cooling (Low - High, dB(A)): 28 / 31 / 37 | · | Sound Level - Heating (Low - High, dB(A)): 28 / 31 / 37 |
| · | Current - Cooling [in+outdoor] (Rated / Max.): 3.4 / 8.16 A | · | Current - Heating [in+outdoor] (Rated / Max.): 4.0 / 8.16 A |
| · | Air volume - Cooling (High, Litre/sec): 167 | · | Air volume - Heating (High, Litre/sec): 167 |
| · | Refrigerant: R410A | · | Liquid pipe size (OD, mm): 6.35 |
| · | Gas pipe size (OD, mm): 9.52 | · | Max. pipe length (m): 20 |
| · | Max. pipe height (m): 12 | · | Power supply: 230V +/- 10% / Single Phase / 50 Hz |
| · | Panel Dimensions (WxDxH, mm): 650 x 650 x 20 | · | Panel Weight: 3kg |
| · | Dimensions (WxDxH, mm): 570 x 570 x 235 | · | Weight: 16.5 kg |
| · | *Note: H2 is approximate (calculated data only) | |
