| PRODUCT RANGE | INVERTER MULTI-SPLIT SYTEMS - R410A | SMALL INVERTER MULTI-SPLIT SYSTEM | INDOOR UNITS FOR MXZ VA SERIES |
|
|
|
|
|

|
|
| Deluxe DC Inverter High Wall with Plasma Duo Filter System |
|
| SRP:
N/A
|
| BDT Code: 68965I |
|
Plasma Duo Deluxe High Wall indoor unit - DC inverter heat pump with the i-see Sensor temperature sensor, Plasma Deodorising & Air Filters, Ozone self-cleaning feature and a Quick Clean Design. Comes with infra red remote and can be used with an optional PAR-21MAA 7 day controller. Cooling/Heating capacity: 5.0/6.0kW. (WxDxH, mm): 798 x 257 x 295. Weight: 12kg. Liquid / Gas Pipe (OD, mm): 6.35 / 12.7. Requires a MUZ-FB50VA outdoor unit or can be used in a customisable MXZ-2A52, 3A54, 4A/B71, 4A/B80, 5A/B100 or 8A140VA Multi-Split System. |
|
* Note:
A single split system uses the outdoor unit: MUZ-FB50VA.
|
|
|
Features
|
|
|
Advanced Energy Saving
"i-see Temperature Sensor"
Plasma Duo Filter System
Introducing the state-of-the-art range of Mitsubishi Electric Deluxe Inverter Heat
Pumps featuring the “i-see Sensor”. This advanced sensing technology reduces
energy consumption by maintaining air temperature and controlling air movement
to prevent excessive heating and cooling as well as unnecessary operation.
This range is also specifically designed to combat and reduce common household
allergens and unpleasant odours, providing the optimal air quality that is vital for
asthma and allergy sufferers.
- Compact Flat Panel
- Super Quiet Operation at just 20 dB(A)*
- "i-see" temperature sensor for Uniform Heating
- Long Life Washable Plasma Deodorising Filter
- Long Life Washable Plasma Air Purifying Filter
- Wide Air Flow with Auto Front Panel
- Quick Clean Design
- Energy-saving “Econo Cool”
- Auto Change Over
- 24 Hour Timer
- Optional PAR-21MAA 7 Day Wired Wall Timer
- Longer Piping Length
- Guaranteed performance down to -15°C
*MSZ-FB25VA; 20dBA in Cooling / 20dBA in Heating, MSZ-FB35VA; 20dBA in Cooling / 21dBA in Heating.
ENERGY STAR
ENERGY STAR is the global mark of energy
efficiency. All models in the FB range have been
awarded the ENERGY STAR signalling that they
meet strict energy efficiency guidelines. You can
rest assured these will provide the highest level of energy
efficiency without compromising on performance or quality.
Unique Energy Saving i-see sensor, Provides Efficient Temperature Control
Conventional heat pumps can’t measure factors such as radiant heat or cold draughts that can affect room
temperature. Some areas may therefore be warmer or cooler than others.
The advanced “i-see Sensor” measures room temperature at floor level as well at the unit itself, resulting in greater
temperature control. Unlike standard systems, the “i-see Sensor” automatically moves from side to side, searching
out temperature disparities and directing airflow to specific areas where it is really needed.
Wide airflow of 150° from left to right (90° in cooling mode) ensures all corners of the room are kept
at the optimal selected temperature. The “i-see Sensor” controls air temperature and air movement
to prevent excessive heating or cooling and unnecessary operation. With “i-see Sensor” you
are ensured total comfort while reducing energy wastage.
 |
|
 |
| Cold air tends to drop to floor level, which is often the cause of over cooling. The i-see Sensor detects this
foot-level temperature and adjusts the air outlet temperature to prevent over cooling. |
Warm air tends to rise up from the floor level, which often prevents that zone from warming up. The i-see Sensor
detects this foot-level temperature and adjusts the air outlet flow to provide optimal temperatures. |
"Area Setting" - for waste-free, energy-saving heating and cooling
In AREA mode, efficient heating or cooling is directed where
it is really needed - the right side, left side or the room as a
whole. The sensor can also operate only on the selected side.
Plasma Duo Filter system
The Plasma Duo Filter system keeps the air pure which is ideal for asthma and allergy sufferers.
It has two plasma air purifying functions that work together to remove airborne dirt particles from
micron to nano-size in scale.
Plasma Deodorisation
The Platinum Catalyst Deodorising Filter uses tiny holes as small as 1 nanometer on a surface of
approximately 3,000m² to capture small odourladen substances in the air and break them down
using ozone generated in the Plasma Electrode Unit and the Platinum Catalyst contained in the filter.
Plasma Electrode Unit
A plasma electrode unit is mounted inside the product. Electro-discharge is used to generate
ozone & plasma. The combination of ozone & plasma and two special filters makes a dynamic
plasma air cleaning function.
Plasma Air Purification
An Anti-allergen Electric Enzyme Filter utilises the combined power of static electricity charged
in the filter and the plasma generated in the Plasma Electrode Unit to capture bacteria, pollen
and other allergens in the air, which are then neutralised with the enzyme in the filter.
Self Cleaning "Ozone Shower"
To ensure the coil is clean and free from impurities, the indoor coil will
be automatically cleaned with Ozone after the unit has been operating
in cooling mode.
Ozone (O3) is resolved gradually and naturally into oxygen (O2). This
creates an extremely efficient cleaning process during which resolving
“nascent Oxygen (O)” is produced. The nascent Oxygen strongly oxidises
airborne particles to sterilise and deodorise the air.
The consistency of ozone during ozone showering remains within health regulations.
Inside of indoor unit 0.1ppm. Under the upper limit of acceptable range of ozone gas consistency at
working environment. (Safety limit advised by Japan Society for Occupational Health) In the room 0.01ppm
or less. Under the averaged consistency of ozone at the beach or forest areas.
Maintenance is easy, just wash in water!
To care for both the Plasma Deodorising Filter and
the Plasma Air Purifying Filter, just wash them in
water.
The deodorising ceramic filter, boasts a service
life of about 6 years.
An improved "horizontal vane," for even more pleasant and refreshing airflow
Advanced airflow control supported by a newly configured horizontal vane
directs air at the floor level in heating mode. In cooling mode, the vane angle can
be kept nearly horizontal, for a pleasant and refreshing feeling.
Auto Change Over Function
When the desired temperature is reached, the system automatically
switches between cooling and heating modes. The selected room
temperature can be maintained without user intervention.
For example, when it’s frosty in the early morning the unit will operate on
heating to maintain a set point of 22°C in heating mode. When the sun
rises the unit can switch to cooling to maintain the 22°C set temperature.
Whisper Quiet Operation
Mitsubishi Electric have a long standing reputation for offering
some of the quietest models in the industry.
The Deluxe MSZ-FB range is no exception. At only 20 dB(A) on its lowest
fan speed, the MSZ-FB25VA is super quiet. You want to feel the warmth,
not hear it!
Guaranteed heating performance down to minus 15 degrees.
Not all heat pumps perform when they are needed most. Our range is
guaranteed to effectively provide heating on those cold nights or
mornings when you really need it.
Optional: Instant comfort at your fingertips
The optional wired remote controller (PAR-21MAA*) has
a weekly timer function enabling 8 separate pattern
settings throughout a single day.
An optional "Centralised ON/OFF Controller (MAC-821SC-E*)" can
also be incorporated to regulate all connected rooms in
your home (and enabling ON/OFF selection and
operation status confirmation from one single controller).
* Requires MAC-397IF-E adaptor
|
|
MSZ-FB50VA Specifications
|
|
|
|
|
|
|
| · | Function: Cooling/Heating | · | Type: Single Split, Inverter | | · | Capacity - Cooling: 5.0 kW | · | Capacity - Heating: 6.0 kW | | · | Capacity - Cooling (min. - max.): 0.8 - 5.8 kW | · | Capacity - Heating (min. - max.): 0.9 - 7.8 kW | | · | Power input - Cooling: 1.60 kW | · | Power input - Heating: 1.64 kW | | · | Power input - Cooling (min. - max.): 0.26 - 2.45 kW | · | Power input - Heating (min. - max.): 0.48 - 2.95 kW | | · | EER / Star rating - Cooling: 3.13 / 5.0 | · | COP / Star rating - Heating: 3.66 / 5.5 | | · | Sensible - Cooling: 3.66 kW | · | Dry Mode (Moisture Removal, Litre/hr): 1.7 | | | | | · | H2 Capacity - Heating*: TBA kW | · | H2 Power input - Heating*: TBA kW | | · | H2 COP - Heating*: TBA | | | | | | | · | Operation Range - Cooling: -10 / +46°C | · | Operation Range - Heating: -15 / +24°C | | · | Sound Level - Cooling (Low - Super High, dB(A)): 29 / 39 / 45 / 52 | · | Sound Level - Heating (Low - Super High, dB(A)): 27 / 37 / 43 / 50 | | · | Current - Cooling [in+outdoor] (Rated / Max.): 7.1 / 16.0 A | · | Current - Heating [in+outdoor] (Rated / Max.): 7.3 / 16.0 A | | · | Air volume - Cooling (High, Litre/sec): 247 | · | Air volume - Heating (Super High, Litre/sec): 247 | | · | Refrigerant: R410A | · | Liquid pipe size (OD, mm): 6.35 | | · | Gas pipe size (OD, mm): 12.7 | · | Max. pipe length (m): 30 | | · | Max. pipe height (m): 15 | · | Power supply: 230V +/- 10% / Single Phase / 50 Hz | | · | Dimensions (WxDxH, mm): 798 x 257 x 295 | · | Weight: 12 kg | | · | *Note: H2 is approximate (calculated data only) | |
|
|
Warranty
|
|
|
· 5 year parts and labour warranty. For full details view the:
 Mitsubishi Electric Warranty Card - Pdf Format (50Kb) |
|
For more information
|
|
|
· Product Brochures - click here.
· Product Manuals - click here. |
|
|
· Rating Conditions (AS / NZS 3823):
Cooling – Indoor: 27°C DB, 19°C WB. Outdoor: 35°C DB.
Heating – Indoor: 20°C DB, Outdoor: 7°C DB, 6°C WB.
· Sensible Cooling Conditions, Indoor: 27°C DB, 20°C WB. Outdoor: 35°C DB.
· Dry function will not work when the room temperature
is below 13°C.
· Colour: Heat pump units shown may not be colour accurate,
please ensure you view an actual unit for colour matching.
· Maximum length is inclusive of height differential. i.e. (20m length/12m high)
means the pipe can be 12m high and 8m across for a total length of 20m.
|
All features and specifications are subject to change and amendment at anytime. Where specifications are critical to design or pre-build we advise that you seek confirmation of accuracy from our product management team on (04) 560-9100.
